Rack and pinion actuator mechanism

Features:

Standard media: air, nitrogen or desulfurization gas, which can be customized for products used for acid gas

Product Type: Gravate Gear Pneumatic Execution Agency

Drive method: pneumatic

Certificate: Sil 3, PED 97/23/EC, 2006/42/EC, IP66/IP67M

Control type: open/level, ESD

Main technical performance indicators:

● The design of the compact gear and tooth strips, the entire area of the piston is used to generate output torque.

● The piston with integrated gradia reduces dynamic sealing points and reduces air leakage points.

● Provide dual effects of high -service life or reliability or spring reset

● Rotating angle 90转 ± 5 (adjustable two -way mechanical itinerary limit)

● Output torque can reach 6500Nm

● Hard passivative aluminum shell The electrostatic coating on the upper electrostatic coating of electrostatic coating makes the execution agency apply to the corrosive environment.

● The gear shaft entry at the bottom makes the execution agency easy to disassemble, and the anti -blowing device at the upper end of the shaft makes the execution agency absolutely safe.

● Installation standard
